Detailed World War II-era production illustration of the Douglas B-17F Flying Fortress, 17 x 11, produced by the Douglas Aircraft Company based out of Long Beach, California. Dated February 28, 1942, the printed schematic is labeled "Major Assembly Breakdown" and features a detailed exploded diagram of the four-engined heavy bomber aircraft. In fine condition, with a central vertical fold and creasing to corners.
